The Male Half Of The Hinge Set
Our company, Kunshan Qunju Metal Products Co., Ltd., produces this garage door hinge pin. The model number is QJ-GD1002. This part is also called a pivot hinge. It is the male half. Hinges have two halves. The male half has the pin. The female half has the hole. The pin goes into the hole. Then the two halves can rotate freely. Our garage door hinge pinss has very high machining precision. The pin diameter tolerance is plus or minus 0.05 millimeters. We use steel to make this hinge pin. The surface has zinc plating. Our company has 60 employees. Five of them are R&D staff. When they designed this product, they paid special attention to the chamfer. The head of the pin has a 45-degree chamfer. This helps the installer align the pin with the female hole. No hard hammering is needed. A gentle push slides it in. This small detail improves installation speed. Many customers have praised this.
Environmentally Friendly Plating Process
Our factory follows local environmental rules. We use a cyanide-free zinc plating process. Waste water is treated before discharge. We have an environmental inspection report from the local authorities. If you need this report, we can provide it. Many European customers ask suppliers for environmental certificates. We have them. You can feel safe working with us. How do we control quality? We have a dedicated quality control department. We use a projector to check the pin profile. The projector enlarges the pin 20 times. We can see if the chamfer is correct. We also use thread gauges. But this garage door hinge pin has no threads. So we mainly check the diameter and length. For each batch, we sample 10 pieces. If one piece is bad, we re-check the whole batch.
Product Data Table
|
Parameter |
Details |
|
Model Number |
QJ-GD1002 |
|
Product Name |
Garage door hinge pin (pivot hinge, male half) |
|
Material |
Steel |
|
Surface Finish |
Zinc plated (cyanide-free) |
|
Pin Diameter Tolerance |
±0.05 mm |
|
Chamfer |
45 degrees |
|
Inspection Method |
Projector (20x enlargement) |
|
Sample Rate |
10 pieces per batch |
|
Minimum Order Quantity |
5,000 pieces (mixed batches accepted) |
|
Warranty |
2 years |
Long Warranty And Flexible Ordering
This garage door hinge pins has a two-year warranty. Why so long? Because it is solid steel. It will not break. Even if the zinc coating wears off, the steel itself will not rust quickly. So the warranty is longer than for other parts. We support OEM and ODM. You can send your drawing. We can make different diameters and lengths. The minimum order quantity is 5,000 pieces. If you need fewer, we can discuss. We also support mixed batches. You can put different hinge pin models in one order. We will produce them together. This saves you purchasing cost. We provide samples. You can test first. Custom products are not free for samples. You pay the shipping cost. We accept third-party inspection. We have worked with BV before. They came to inspect one order.
